Aruba Instant On AP12 Indoor Access Points

Small businesses are facing a number of challenges due to new and emerging technology, making it pretty overwhelming to keep up.

Mobile devices and cloud-based applications such as Microsoft Office 365 are changing the way you engage with customers, suppliers and staff. Since it’s tough enough to set up a new payroll system or choose the most effective point of sale system - we believe choosing the best Wi-Fi solution for your business should be simple. Whether you own a café or a trendy boutique hotel, your employees and customers are relying on the network for almost everything they do. And because Wi-Fi plays such a crucial role today, you need a purpose-built solution that keeps your business on the go. Aruba Instant On Access Points (APs) are easy to deploy and manage – with a quality look and feel at an attractive price point

KEY FEATURES

Smart Mesh technology 802.11ac Wave 2, 3X3:3 MU-MIMO technology Remote management and monitoring capability Separate guest and employee Wi-Fi network Mobile app and cloud portal

TECHNICAL SPECIFICATIONS

IN THE BOX

Aruba Instant On AP12 Indoor Access Point Aruba Instant On AP12 Quick Start guide Ceiling rail mount clip Solid surface mount clip Ethernet Cable

RADIOS

Dual Radio for simultaneous dual-band operation 5 GHz 802.11ac 3x3 MIMO for up to 1,300 Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5) 2.4 GHz 802.11n 2x2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4)

INTERFACES

Uplink Gigabit Ethernet port, with POE-in support (802.3af) DC power connector (12V) USB host interface (future use) Bluetooth Low Energy (BLE) radio LED status indicators (2) Reset/LED control button Kensington security slot

PHYSICAL SPECIFICATIONS

157mm x 157mm x 34mm, excluding mount accessories Weight: 483g

POWER

Power over Ethernet (POE): 802.3af (class 3) DC power (12V) Note: Power sources are sold separately

ANTENNAS

Integrated downtilt omni-directional antennas with maximum individual antenna gain of 3.9dBi in 2.4GHz and 5.4dBi in 5GHz

MOUNTING

The access point ships with a (black) mount clip to attach to suspended ceiling rails, and a (white) mount clip to attach to solid surfaces (wall/ceiling)

ENVIRONMENTAL & RELIABILITY

Operating Temperature: 0° C to +50° C (+32° F to +122° F) Humidity: 5% to 93% non-condensing MTBF: 1,116khrs (127yrs) at +25° C

INDUSTRY CERTIFICATIONS

UL 2043 plenum rating EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments) Wi-Fi Alliance certified (WFA) 802.11ac with Wave 2 (Wi-Fi 5), WPA2, WPA3, Enhanced Open (OWE)

MANAGEMENT OPTIONS

Instant On mobile application (Android & iOS) Cloud Portal: Portal.ArubaInstantOn.com

WARRANTY & SUPPORT

Aruba Instant On 1 Year warranty with 24X7 phone support for first 90 days and chat support for the entire warranty period. Community support as long as you own the products
